Application area
- Manually guided shape cutting
- Straight cutting by means of an L-bar
- Straight cutting by means of guide rail
- Circle cutting up to 1600 mm Ø by means of a circle cutting attachment
- Bevel cutting
- Bevel cutting with muliple torches (X- or Y- cuts)
Scope of delivery
- 1 machine cutting torch (acetylene or propane), (The machine is prepared for the connection of 2 additional torches)
- 1 steel box with block nozzles for 3 – 100 mm thickness
- 1 set of cleaning needles
- 1 universal wrench
- 1 pistol-shaped igniter
- 1 circle cutting attachment 16 mm x 558 mm
- 1 counter weight with adjustable center
- 5 m main cable with shock-proof plug
Details
| Schneidbereich: | 3 – 100 mm / 200 mm |
|---|---|
| Gasarten: | Acetylen oder Propan |
| Brennereinstellung: | Seiten-, Höhenverstellung, Schrägstellung mit Winkelskala |
| Elektr. Antrieb: | Stufenlos regelbar |
| Vorschub" | 50 – 900 mm / min |
| Spurbreite: | 150 mm |
| Länge: | 540 mm |
| Gewicht: | ca. 19,5 kg |
| Spannung: | 230 VAC / 42 VDC wahlweise |
| Aufnahmeleistung: | 45 W |
